Table 3. SCB address settings, RFL DS-TT Transfer Trip Module
Module Address SW1-1 SW1-2 SW1-3 SW1-4 SW1-5
1 DOWN DOWN DOWN DOWN UP
2 DOWN DOWN DOWN UP DOWN
3 DOWN DOWN DOWN UP UP
4 DOWN DOWN UP DOWN DOWN
5 DOWN DOWN UP DOWN UP
6 DOWN DOWN UP UP DOWN
7 DOWN DOWN UP UP UP
8 DOWN UP DOWN DOWN DOWN
9 DOWN UP DOWN DOWN UP
10 DOWN UP DOWN UP DOWN
11 DOWN UP DOWN UP UP
12 DOWN UP UP DOWN DOWN
13 DOWN UP UP DOWN UP
14 DOWN UP UP UP DOWN
15 DOWN UP UP UP UP
16 UP DOWN DOWN DOWN DOWN
17 UP DOWN DOWN DOWN UP
18 UP DOWN DOWN UP DOWN
19 UP DOWN DOWN UP UP
20 UP DOWN UP DOWN DOWN
21 UP DOWN UP DOWN UP
22 UP DOWN UP UP DOWN
23 UP DOWN UP UP UP
24 UP UP DOWN DOWN DOWN
25 UP UP DOWN DOWN UP
26 UP UP DOWN UP DOWN
27 UP UP DOWN UP UP
28 UP UP UP DOWN DOWN
29 UP UP UP DOWN UP
30 UP UP UP UP DOWN
31 UP UP UP UP UP
