16 FRONT

PANEL LEDs

DS1 TO DS16

LATCHES

LATCH

SCB

ADDRESS

SWITCHES

SW1

STATUS

LOCK

SWITCH

SW2

ACTEL

SCB

FPGA

ACTEL

STATUS

FPGA

BUFFERS

RAM

ROM

80C320

MICRO-

CONTROLLER

11.0592

MHZ

CLOCK

WATCHDOG

TIMER

AND RESET

STATUS

I/O

STATUS INPUT

STATUS OU

TPUT

T1/E1

BUS

FROM/TO

COMMON

MODULE

VIA SCB BUS

LEVEL

CONVERTER

FOR

RS232

PORT

DATA & CONTROL LINES

IN OUT

ALARM

LED

DS17

Figure 6. Status Module Block Diagram

RFL Status Module RFL Electronics Inc.

July 15, 2007 13 (973)

334-3100
