RFL TMX/TMR RFL Electronics Inc.
January 25, 2012 10 (973) 334-3100
Table 4. Controls and indicators, RFL TMX Telemetry Transmitter module
Item Name/Description Function Setting
1 DIP switch SW1 (SW1-1 thru - 6) Selects SCB address See Table 6
SW1-7 Spare NA
SW1-8 Spare NA
2 DIP switch SW2 (SW2-1 thru - 5) Time slot select See Table 7
SW2-6 Spare NA
SW2-7 Selects Local or Remote control UP: Remote control
DOWN: Local control
SW2-8 Sets module service ON or OFF UP: Service ON
DOWN: Service OFF
3 DIP Switch SW3 (SW3-1 thru –6) Selects TMX address See Table 8
SW3-7 Spare NA
SW3-8 Selects Term/DIA or DIB OFF: DIB
ON : Terminal/DIA
4 DIP Switch SW4 (SW4-1 thru -3) Calibrator Select See Table 5
SW4-4 Spare NA
SW4-5 Selects live data or fixed value OFF: Live data
for analog channel 4 A/D converter
output
ON: Fixed value = 0
SW4-6 Selects live data or fixed value OFF: Live data
for analog channel 3 A/D converter
output
ON: Fixed value = 0
SW4-7 Selects live data or fixed value OFF: Live data
for analog channel 2 A/D converter
output
ON: Fixed value = 0
SW4-8 Selects live data or fixed value OFF: Live data
for analog channel 1 A/D converter
output
ON: Fixed value = 0
5 DIP Switch SW5 (SW5-1 and –2) Analog channel 4 input gain select SW5-1 SW5-2 input gain
ON ON 8
ON OFF
4
OFF ON
2
OFF OFF
1
(SW5-3 and –4) Analog channel 3 input gain select SW5-3 SW5-4 input gain
ON ON 8
ON OFF
4
OFF ON
2
OFF OFF
1
(SW5-5 and –6) Analog channel 2 input gain select SW5-5 SW5-6 input gain
ON ON
8
ON OFF
4
OFF ON 2
OFF OFF 1
(SW5-7 and –8) Analog channel 1 input gain select SW5-7 SW5-8 input gain
ON ON
8
ON OFF
4
OFF ON
2
OFF OFF
1
6 LED Indicator DS1 Lights when TMX service is ON NA
