Table 7. Time Slot Select for RFL TMX and TMR modules.
Switch Equivalent T1 E1
Code “P” Channel 1 Channel 1
(Decimal) 1 2 3 4 5 Code Time Slot Time Slot
0 D D D D D 00000 * *
1 D D D D U 00001 1 1
2 D D D U D 00010 2 2
3 D D D U U 00011 3 3
4 D D U D D 00100 4 4
5 D D U D U 00101 5 5
6 D D U U D 00110 6 6
7 D D U U U 00111 7 7
8 D U D D D 01000 8 8
9 D U D D U 01001 9 9
10 D U D U D 01010 10 10
11 D U D U U 01011 11 11
12 D U U D D 01100 12 12
13 D U U D U 01101 13 13
14 D U U U D 01110 14 14
15 D U U U U 01111 15 15
16 U D D D D 10000 16 *
17 U D D D U 10001 17 17
18 U D D U D 10010 18 18
19 U D D U U 10011 19 19
20 U D U D D 10100 20 20
21 U D U D U 10101 21 21
22 U D U U D 10110 22 22
23 U D U U U 10111 23 23
24 U U D D D 11000 24 24
25 U U D D U 11001 * 25
26 U U D U D 11010 * 26
27 U U D U U 11011 * 27
28 U U U D D 11100 * 28
29 U U U D U 11101 * 29
30 U U U U D 11110 * 30
31 U U U U U 11111 * 31
Physical Switch Settings
SW2-
Notes: 1. * This setting is not allowed . Setting switches to
this code will cause the module’s service to be disabled.
2.
D = down, U = up.
3. DIP-swi
tch settings are used in local control, and P-codes are used in remote control. See Tables 13 and 17
for P1-codes.
RFL TMX/
TMR RFL Electro
nics Inc.
January 25, 2012 13 (973)
334-3100
