Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL TMX/TMR RFL Electronics Inc.
January 25, 2012 15 (973)
334-3100
Table 8. continued - Address Settings for RFL TMX and TMR modules
TMX/TMR
Address
SW3-1 SW3-2 SW3-3 SW3-4 SW3-5 SW3-6
46 ON OFF ON ON ON OFF
47 ON OFF ON ON ON ON
48 ON ON OFF OFF OFF OFF
49 ON ON OFF OFF OFF ON
50 ON ON OFF OFF ON OFF
51 ON ON OFF OFF ON ON
52 ON ON OFF ON OFF OFF
53 ON ON OFF ON OFF ON
54 ON ON OFF ON ON OFF
55 ON ON OFF ON ON ON
56 ON ON ON OFF OFF OFF
57 ON ON ON OFF OFF ON
58 ON ON ON OFF ON OFF
59 ON ON ON OFF ON ON
60 ON ON ON ON OFF OFF
61 ON ON ON ON OFF ON
62 ON ON ON ON ON OFF
63 ON ON ON ON ON ON
TMR Telemetry Receiver Installation
The following instructions are provided for installing an RFL TMR Telemetry Receiver module into
an existing system. If the module was included as part of a system, installation was done at the factory.
Otherwise, proceed as follows:
1. Carefully inspect the module for any visible signs of shipping damage. If you suspect damage
to the module, immediately call RFL Customer Service at the number listed at the bottom of
this page.
2. Determine the module slot in the Main Chassis or Expansion Chassis where the TMR module
will be installed. The RFL TMR Telemetry Transmitter module occupies one module slot in the
Main Shelf or Expansion Shelf.
3. Each module in the IMUX 2000 multiplexer requires a Module Adapter. The module adapter
provides the appropriate connector for the desired interface. The Module Adapter that is used
with the TMR is the MA-700 as shown in Figure 1.
4. On the MA-700 module adapter select a single ended or differential input for analog channels
1, 2, 3 and 4 using the programmable jumpers shown in Table 3 as applicable.
5. The information in this step is provided for users who wish to modify the output ranges of the
TMR through the use of external conversion resistors on the MA-700 module adapter. Table 1
describes what combinations of TMX inputs and TMR outputs require conversion resistors. If
conversion resistors are not required in your installation, go to step 6.
