Table 22. Remote status messages (“S” codes) for the RFL TMR module
S Code Position Value Description
S1 B 0 0 0 0 0 0 0 0
- - - - - - - ↑
0 T1 is detected
T1/E1 AUTO DETECT
1 E1 is detected
B 0 0 0 0 0 0 0 0
- - - - - - ↑ -
0 SCB configuration correct
SCB
CONFIGURATION
1 SCB configuration errors detected
B 0 0 0 0 0 0 0 0
- - - - - ↑ - -
0 TMX and TMR addresses do not match
ADDRESS
TEST RESULT
1 TMX and TMR addresses do match
or address test disabled (See P2 TMR code)
B 0 0 0 0 0 0 0 0
- - - - ↑ - - -
0 Data frame lock not achieved
TELEMETRY
FRAME SYNC
1 Data frame lock achieved
B 0 0 0 0 0 0 0 0
- - - ↑ - - - -
0 Correct status
TPU SIGNAL
(common module loss of
frame alignment signal)
1 Incorrect status
S2
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
1111 1111 to
0111 1111
MS byte of received analog channel 1 transmitter data in
signed m
agnitude format.
S3
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
1111 1111 to
0111 1111
MS byte of received analog channel 2 transmitter data in
signed m
agnitude format.
S4
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
1111 1111 to
0111 1111
MS byte of received analog channel 3 transmitter data in
signed m
agnitude format.
S5
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
1111 1111 to
0111 1111
MS byte of received analog channel 4 transmitter data in
signed m
agnitude format.
