Chapter 5 - Use of the SETUP Menu
SNMP Access Gateway User’s Manual - v1.0 -- 11/99 - Page 16
C. 1200
D. 2400
E. 4800
F. 9600
G. 19200
Selection [G]?
Setup: Serial Ports: I/O 1 W,P,S
A. 8,N,1
B. 7,E,1
C. 7,O,1
D. 7,N,1
Selection [A]?
DTR Low Except When Pass-Through Active [N]?
This last option turns on or off DTR handshaking with the device connected to I/O port 1 or 2 that one is accessing
directly. In its default state, DTR is always high to the device on the respective port. With this option set to Y(es),
DTR will go low to the device when no direct serial access is occurring. This is useful if one wants the device to
close any maintenance or administrative session automatically in the case where a connection was not terminated
properly.
5.3 - Passwords
Selecting the Menu Letter of PASSWORDS from the Setup Main Menu presents the following submenu for setting
the SNMP Access Gateway passwords. The menu below shows the default passwords.
Setup: Passwords
A. Command Password [SL60]
B. Pass-Through Port 1 Password [ACCESS1]
C. Pass-Through Port 2 Password [ACCESS2]
D. FTP Server Password [SL60]
Selection?
5.4 - Event Definitions
Selecting the Menu Letter of EVENT DEFINITIONS from the Setup Main Menu presents the following submenu
for setting up the various events and alarm capabilities of the SNMP Access Gateway.
Setup: Event Definitions
A. Set up Sensor / Analog Events
B. UpLoad New Filter and Alarm File
C. View Current Filter and Alarm File
D. Alarm Evaluator Enabled [ Y]
E. Store Data Record Events [Y]
F. Store Alarm Record Events [Y]
G. Store Sensor Events [N]
H. Store Reset Events [N]
I. Store Command Log Events [N]
5.4.1 - Set Up Sensor/Analog Events
Selecting the Menu Letter of this option presents the following submenu for selection of various options relating to
enabling and configuring the Contact Closure/Analog inputs for use.
Setup: Event Definitions: Sensor Events
Sensor Set Type Name Active Thrsh Actions
1. Sensor 1 Y CC fire Closed 1 (T)12
