Chapter 12 - Use of the EVENTS command
SNMP Access Gateway User’s Manual - v1.0 -- 11/99 - Page 45
Chapter 12 - Use of the EVENTS Command
Th
e EVENTS command enters a menu which allows you to view and control matters relating to existing or past
Event (Alarm) conditions. Within this section you can view the current condition of sensor inputs and serial alarm
parameters, records of all past events, and view and clear currently outstanding alarm conditions.
Events Main Menu
A. List Events File (0 Records)
B.
Clear Events File
C. View Active Alarms
D. Acknowledge Active Alarms
E. View Alarm Action Detail
F. View Data Alarm Counters
G. View Action History
H. Clear Action History
12.1 - List Events File
Selecting the Menu Letter of this option allows you to view and optionally or clear the Events File. The Events File
is a stored log of all events recorded by the SNMP Access Gateway. This log can also be transferred and deleted
using FTP, which is covered in another chapter. Upon selection of this menu item the events log will be listed out as
shown below and a prompt will allow you to pause and clear the records which have been shown. Below is an
example of an Events File listing. Notice that the last ‘DATA’ record which was received also matched an Alarm
Formula and so this record was stored in the events file twice, once as a data record and once as an alarm record.
04/08/98 11:59 DATA 2 N 021 00 T002014 DN6502 02/25 09:22 00:00:10
04/08/98 11:59 DATA 2 N 022 00 T007002 DN5700 02/25 09:19 00:02:36
04/08/98 11:59 DATA 2 E 023 00 T002024 DN1006 02/25 09:22 00:00:58
04/08/98 11:59 DATA 2 N 024 00 T002042 DN6000 02/25 09:21 00:00:46
04/08/98 11:59 ALARM equalfour 2 N 024 00 T002042 DN6000 02/25 09:21 00:00:46
<enter>-More C-Clear Events X-Exit
12.2 - Clear Events File
Selecting the Menu Letter of this option clears any existing records currently logged in the Events File. Upon
selection of this menu item you are prompted with a Sure prompt, and answering ‘Y’ to this prompt clears the log.
Sure? (Y/N) Y
12.3 - View Active Alarms
Selecting the Menu Letter of this option shows the following display representing the current state and alarm status
of sensor inputs and data alarms. Note the asterisks in the display below. These indicate an active alarm condition
for the associated alarm. Since there can potentially be more data alarms than can be displayed on a screen, this
display is intended to give a quick indication of the presence of data alarms which can then be queried in more detail
using another option in this section. The position of the asterisks in the display below correspond to the order of the
data alarm formulas as defined in the Alarm File (covered in another section herein).
Data Alarms : *-----*-------*---------------
Sensor Alarms :
1 fire CC Closed *
2 smoke CC Closed *
3 flood CC Open -
4 famine CC Open -
5 pestilence CC Open -
6 layoffs CC Open -
