SERVICE PROGRAM MODE
B121 Series/B259 Series 5-4 SM
1007
Display By-pass
1007 1 Display By-pass Displays the by-pass paper width switch output.
Fusing Idling
1103*
This program decides the action of the Fusing Drive Release Mechanism (
6.13.2). When you select "1," the contact/release control is disabled and the drive
power is always transmitted to the fusing unit. As a result, the machine takes a
longer time to warm up the fusing unit. Use SP1-103-001 if fusing quality is low
even when the room temperature is not very low.
1103 1 Fusing Idling [0 = No / 1 = Yes]
Fusing Temperature Adjustment
1105*
Adjusts the target fusing temperature. "Center" indicates the center of the roller;
"End" indicates the front and rear ends.
1105 1 Warm Up-Center
1105 2 Warm Up-End
[140 ~ 180 / 160 / 1°C/step]
1105 3 Standby-Center [140 ~ 170 / 155 / 1°C/step]
1105 4 Standby-End [140 ~ 165 / 150 / 1°C/step]
1105 5 Copying-Center
1105 6 Copying-End
[140 ~ 185 / 160 / 1°C/step]
1105 7 Low Level 2-Center
1105 8 Low Level 2-End
[0 ~ 80 / 60 / 1°C/step]
1105 9 Thick-Center
1105 10 Thick-End
[140 ~ 185 / 175 / 1°C/step]
1105 11 Warm Up Low-Center
1105 12 Warm Up Low-End
[140 ~ 180 / 170 / 1°C/step]
1106
Display Fusing
1106 1 Displays the fusing temperature.
Fusing Soft Start
1107*
Adjusts the number of zero-cross cycles of the fusing lamp AC supply needed to
bring the fusing lamp power to 100% while bringing the lamp up to the standby
temperature or while copying. Increase this value if the machine is experiencing
sudden power dropouts ( 6.13.5).
1107 1 Warm Up Soft Start [0 = 10 cycles / 1 = 20 cycles / 2 = 50 cycles]
1107 2 Other Soft Start [0 = 5 cycles / 1 = 10 cycles / 2 = 20 cycles]
1108*
Set-Fusing Start [0 = 1s / 1 = 1.5s / 2 = 2s]
1108 1 Specifies the interval for fusing-temperature control ( 6.13.5).
1109
Nip Band Check
1109 1 Checks the fusing nip band ( 3.10.8).
