COMPONENTS
B621 4 SM
2. DETAILED DESCRIPTION
2.1 COMPONENTS
1. Exit rollers
2. Tray open switch
3. Paper sensor
4. Exit sensor
5. Tray motor
6. 1-bin tray board
7. Junction gate solenoid
8. Exit tray LED
9. Tray open switch
10. Exit sensor
11. Junction gate
12. Junction gate solenoid
13. Paper sensor
B621D901.WMF
B621D902.WMF
B621D907.WMF
B621D903.WMF
1
2
3
4
5
7
8
10
11
12
13
9
6
