ELECTRICAL COMPONENT LAYOUT
B379 2 SM
1.2 ELECTRICAL COMPONENT LAYOUT
1. DF Feed Clutch
2. Feed Cover Sensor
3. Original Width Sensor Board
4. Original Length Sensor 1
5. DF Pick-up Solenoid
6. Original Length Sensor 2
7. Junction Gate Solenoid
8. DF Drive PCB
9. DF Position Sensor
10. DF Feed Motor
11. DF Transport Motor
12. Original Exit Sensor
13. Stamp Solenoid
14. Original Trailing Edge Sensor
15. Original Set Sensor
16. Original Reverse Sensor
17. Registration Sensor
B379D202.WMF
2
1
16
15
17
14
13
12
11
10
9
8
7
6
5
4
3
