PM TABLES
B121 Series/B259 Series 2-2 SM
Fusing Unit
EM 60k
120k
AN NOTE
Hot roller R
Pressure roller R
Pressure roller cleaning roller R
Hot roller bushings I
Pressure-roller bushing R
Hot roller stripper pawls R C Dry cloth
Thermistor C C Dry cloth
ADF/ARDF
80k AN NOTE
Feed belt R C Clean with water or alcohol.
Separation roller R C Clean with water or alcohol.
Pick-up roller R C Clean with water or alcohol.
Stamp R Replace when necessary.
White plate C Clean with water or alcohol.
DF exposure glass C Clean with water or alcohol.
Platen cover C Clean with water or alcohol.
Paper Tray Unit
60k 120k AN NOTE
Paper feed rollers R C Dry or damp cloth
Bottom-plate pads C C Dry cloth
Paper-feed guides C C Clean with water or alcohol.
Friction pads R C Dry or damp cloth
Relay clutch (B384 only) I
Feed clutches (B384 only) I
Relay roller (B384 only) C C Dry cloth
To Next Page
