Ricoh B121 - Two-Tray Paper Tray Unit

SPECIFICATIONS
SM 7-17 B121 Series/B259 Series
Specifications
TWO-TRAY PAPER TRAY UNIT
Paper Size:
A5 to A3
51/2" x 81/2" SEF to 11" x 17"
Paper Weight: 60 – 105 g/m
2
, 16 – 28 lb.
Tray Capacity: 500 sheets (80 g/m
2
, 20 lb.) x 2 trays
Paper Feed System: Feed roller and friction pad
Paper Height Detection: 4 steps (100%, 70%, 30%, Near end)
Power Source: 24 Vdc, 5 Vdc (from the copier/printer)
120 Vac:
120 V version, from the copier/printer when the
optional tray heater is installed
220 – 240 Vac:
230 V version, from the copier/printer when the
optional tray heater is installed
Power Consumption: Max: 30 W (Copying/printing)
23 W (Optional Tray Heater On)
Average: 17 W (Copying/printing)
15 W (Optional Tray Heater On)
Weight: 25 kg (55 lb.)
Size (W x D x H): 550 mm x 520 mm x 271 mm
One-Bin Tray
Paper Size: Width: 140 ~ 297 mm
Length: 140 ~ 432 mm
Output Standard Position: Center
Paper Weight: 60 ~ 105 g/m², 16 ~ 28 lbs.
Tray Capacity: 100 sheets (A4 LEF 80 g/m
2
, 20 lb)
Power Source: 5 VDC, 24 VDC (from the copier)
Power Consumption: Max. 20 W
Weight:
1.55 kg (Base unit: 1.1 kg, Tray: 0.45 kg)
Size (W x D x H):
461 mm x 478 mm x 104 mm
(508 mm x 478 mm x 104 mm when tray extended)
