Ricoh B121 - Drive Layout

ARDF
B379
DRIVE LAYOUT
SM 3 B379
1.3 DRIVE LAYOUT
1. Separation Roller
2. Original Feed Belt
3. Pick-up Roller
4. DF Feed Clutch
5. DF Transport Motor
6. DF Feed Motor
7. Reverse Table Roller
8. 2nd Transport Roller
9. Exit Roller
10. 1st Transport Roller
B379D203.WMF
4
10
1
2
3
6
5
9
8
7
