IEEE1284/IEEE1394 INTERFACE
B121 Series/B259 Series 1-42 SM
1.13.1 ACCESSORY CHECK
Check the quantity and condition of the accessories.
No. Description Q’ty
1 Wireless LAN card 1
2 Wireless LAN card cover 1
3 Wireless LAN board 1
1.13.2 INSTALLATION PROCEDURE
CAUTION
Unplug the machine power cord before starting the following procedure.
NOTE:
1) Before installing the optional wireless LAN (IEEE 802.11b), install the
optional printer scanner.
2) One slot is available. You can install ONLY one of the following options
at one time: IEEE1284 interface, IEEE1394 interface, wireless LAN
interface, or Bluetooth interface..
1. Remove the slot cover [A] ( x 2).
2. Install the wireless LAN (IEEE 802.11b)
board [B] ( x 2).
3. Reattach the rear cover.
B682I901.WMF
[B]
[A]
