DF EXIT TABLE AND COVER
B379 18 SM
3. REPLACEMENT AND ADJUSTMENT
3.1 DF EXIT TABLE AND COVER
1. Open the left cover.
2. [A] Front cover ( x 2)
3. [B] Rear cover ( x 2). Take care not to break the 3 hooks.
4. [C] Open the reverse table
5. [D] Original exit table ( x 3)
B379R506.WMF
[C]
[A]
[D]
[B]
