Ricoh B121 - SP3-XXX (Machine Set); SP4-XXX (ROM Versions)

SERVICE PROGRAM MODE
SM 17 B620
Fax Option
B620
SP3-XXX (Machine Set)
3
Mode No. Function
Service Station 101
001 Fax Number Enter the fax number of the service station.
Serial Number 102
001 Enter the fax unit’s serial number.
PSTN-1 Port Settings
001 Select Line
Select the line type setting for the G3-1 line.
If the machine is installed on a PABX line,
select “PABX”, “PABX(GND)” or
“PABX(FLASH)”.
002 PSTN Access Number
Enter the PSTN access number for the
G3-1 line.
103
003
Memory Lock
Disabled
If the customer does not want to receive
transmissions using Memory Lock on this
line, turn this SP on.
FAX Switches 201
001 – 032 00 – 1F
Change the bit switches for scanner
settings for the fax option
 Section 3.2 Bit Switches
SP4-XXX (ROM Versions)
4
Mode No. Function
001 FCU ROM Version
002 FCU ROM Version P/N
003 FCU ROM Version Ver.
004 FCU ROM Version Area
005 FCU ROM Version Date
006 FCU ROM Version Drer.
101
007 FCU ROM Version sum.
Displays the FCU ROM version.
102 001 Error Codes Displays the latest 64 fax error codes.
001 G3-1 ROM Version
002 G3-1 ROM Version Parts No.
003 G3-1 ROM Version Control
103
004 G3-1 ROM Version DSP
Displays the G3-1 modem version.
