ARDF INSTALLATION
SM 1-9 B121 Series/B259 Series
Installation
1.4 ARDF INSTALLATION
1.4.1 ACCESSORY CHECK
Check the quantity and condition of the accessories against the following list.
No. Description Q’ty
1 Scale Guide 1
2 DF Exposure Glass 1
3 Stud Screw 2
4 Knob Screw 2
5 Original Size Decal 2
6 Screwdriver Tool 1
7 Attention Decal—Top Cover 1
1.4.2 INSTALLATION PROCEDURE
CAUTION
Unplug the copier power cord before starting the following procedure.
1. Remove the strips of tape.
B379I901.WMF
B379I101.WMF
1
2
3
4
5
6
7
