MFP EXPANSION
SM 1-39 B121 Series/B259 Series
Installation
Step 9–Printer/Scanner and Fax Keys
1. Remove the dummy cover (from the basic operation panel) and install the copy
key [A] or [a].
2. Remove the dummy panel (from the basic operation panel) and install the fax
panel [B].
3. Install the scanner key [C] or [c] on the optional operation panel.
4. Install the fax panel [D] on the optional operation panel.
5. Install the fax key [E] or [e] on the optional operation panel.
6. Remove the dummy panel (from the basic panel) and install the printer panel
[F].
7. Install the printer key [G] or [g] on the basic operation panel.
Copy
Scanner
PrinterFacsimile
B658I911.WMF
[A]
[a]
[G]
[g]
[E]
[e]
[C]
[c]
[D] [B][F]
