BIT SWITCHES
SM 49 B620
Fax Option
B620
3.2.6 FAX SWITCHES
FAX Switch 00 - Not used (Do not change the settings.)
:
:
FAX Switch 0A - Not used (Do not change the settings.)
FAX Switch 0B SP No. 3-201-012
No FUNCTION COMMENTS
0
to
3
Scan margin setting (right and left margin in book scan ADF mode)
The setting can be between 0 and F (H) (unit 0.5 mm).
Default setting: 2 mm
4
to
7
Scan margin setting (top and bottom margin in book scan and ADF mode)
The setting can be between 0 and 7 (H) (unit 0.5 mm).
Default setting: 3 mm
FAX Switch 0C SP No. 3-201-013
No FUNCTION COMMENTS
0
Action when an original jam has
occurred while scanning the original
into memory for memory tx
0: Continues scanning after
recovery
1: Stops scanning and erases all
scanned pages for that job
This bit is only effective when parallel memory tx is
disabled (user parameter 07 - bit 2).
If parallel memory tx is enabled, the machine always
erases the scanned pages when an original jam
occurs. The machine then asks the user to retry from
the first page, even if the parallel memory tx is not
actually used.
0: The machine displays a message asking the user to
put the jammed page back into the original stack, and
continues scanning.
The message is displayed for the time period specified
by scanner switch 0E, bit 2.
1: The machine erases all the scanned pages and
asks the user to retry from the first page.
1
to
2
Setting when an original size cannot
be recognized
Bit 2 1 Setting
0 0 No original
0 1 A5
1 0 A5
1 1 No original
3-7 Not used Do not change the settings.
FAX Switch 0D SP No. 3-201-014
No FUNCTION COMMENTS
0-6 Not used Do not change the settings.
7
Scan width for A5 lengthwise or
B5 lengthwise originals
0: 210 mm (8.5”)
1: Original width
0: The machine scans the original as 210 mm (8.5")
width. The transmitted image has a blank area on
the right.
1: The machine scans 148 mm (A5) or 182 mm
(B5) and centers the scanned data on a 216 mm
width transmitted image.
To Next Page
