SERVICE PROGRAM MODE
SM 5-85 B121 Series/B259 Series
Service
Tables
TEST PATTERN PRINT (SP5-902-1)
Executing Test Pattern Printing
1. Specify the pattern number and press the OK key.
2. Press the copy start key. The copy mode is activated ( "Activating Copy
Mode" in section 5.1.1).
3. Specify copy settings and press the  key.
4. To return to the SP mode, press the  key.
Test Patterns
Test Patterns Using VCU Test Patterns Using IPU
No. Pattern No. Pattern
0 (No print) 30 Vertical Lines (Single Dot)
1 Vertical Lines (Single Dot) 31 Horizontal Lines (Single Dot)
2 Horizontal Lines (Single Dot) 32 Vertical Lines (Double Dot)
3 Vertical Lines (Double Dot) 33 Horizontal Lines (Double Dot)
4 Horizontal Lines (Double Dot) 34 Isolated Four Dots
5 Grid Pattern (Single Dot) 35 Grid Pattern (Double Dot)
6 Grid Pattern (Double Dot) 36 Black Band (Vertical, 1024 Dots)
7 Alternating Dot Pattern 37 Grayscales (Horizontal, 512 Dots)
8 Isolated one dot 38 Grayscales (Vertical, 256 Dots)
9 Black Band (Horizontal) 39 ID Patch
10 Trimming Area 40 Cross
11 Argyle Pattern (Single Dot) 41 Argyle Pattern (128-Dot Pitch)
12 Grayscales (Horizontal) 42 Square Gradation (64 Grades)
13 Grayscales (Vertical) 43 Square Gradation (256 Grades)
14 Grayscales (Vertical/Horizontal) 44 Grayscales (Horizontal, 32-Dot Width)
15 Grayscales (Vertical/Horizontal Overlay) 45 Grayscales (Vertical, 32-Dot Width)
16 Grayscales With White Lines (Horizontal) 46 Trimming Area (A3)
17 Grayscales with White Lines (Vertical) 47 A4 Gradation Patches 1 (128 Grades)
48 A4 Gradation Patches 2 (128 Grades) 18 Grayscales with White Lines
(Vertical/Horizontal)
49 Trimming Area (A4)
Test Patterns Using SBU
No. Pattern
51 Grid Pattern (double dot)
52 Gray scale 1 (256 grades)
53 Gray scale 2 (256 grades)
