IMAGE FUSING AND PAPER EXIT
SM 6-59 B121 Series/B259 Series
Detailed
Descriptions
6.13 IMAGE FUSING AND PAPER EXIT
6.13.1 OVERVIEW
1. Paper exit roller
2. Exit sensor
3. Hot roller strippers
4. Pressure roller
5. Cleaning roller
6. Pressure spring
7. Fusing lamps
8. Thermistor
9. Thermostat
10. Hot roller
11. Thermostat
B121D901.WMF
3
2
1
9
4
6
8
11
7
5
10
