SERVICE PROGRAM MODE
B121 Series/B259 Series 5-78 SM
INPUT CHECK (SP5-803)
Conducting an Input Check
1. Select SP5-803.
2. Select the number (see the table below) corresponding to the component.
3. Select "Execute." The copy mode is activated.
4. The sign "01H" or "00H" is displayed (see the table below).
Input Check Table
Num. Sensor/Switch 01H 00H
001 Safety SW Open Closed
002 Safety SW-LD 5V Open Closed
003 Right Cover SW Open Closed
004 Right Low Cover SW Open Closed
005 Tray Cover SW Open Closed
006 Upper Relay S Paper detected Not detected
007 Lower Relay S Paper detected Not detected
008 Vertical Trans S Paper detected Not detected
009 Registration Sensor Paper detected Not detected
010 Exit Sensor Paper detected Not detected
011 Duplex Inverter S Paper detected Not detected
012 Duplex Entrance S Paper detected Not detected
013 Duplex Exit S Paper detected Not detected
014 By-pass PE S Paper detected Not detected
015 By-pass P Size S *1
016 Upper PE S Paper detected Not detected
017 Lower PE S Paper detected Not detected
018 Upper P Size SW *1
019 Lower P Size SW *1
020 BK-Upper Paper End S Paper detected Not detected
021 BK-Lower Paper End S Paper detected Not detected
022 BK-Up P Size SW *1
023 BK-Low P Size SW *1
024 BK-Up P Height S *2
025 BK-Low P Height S *2
026 BK-Upper Lift S At upper limit Not at upper limit
028 BK type *3
030 Duplex Installed Installed Not installed
031 Lower Lift S At upper limit Not at upper limit
032 Main M Lock Locked Not locked
033 Polygon M Lock Locked Not locked
034 BK-Lift M Lock Locked Not locked
035 Total CO Install Installed Not installed
036 Key CO Install Installed Not installed
037 L-Synchronization Detected Not detected
038 DF-Position S Detected Not detected
039 DF-Cover Open S Detected Not detected
040 DF-Original Set S Detected Not detected
