MFP EXPANSION
SM 1-33 B121 Series/B259 Series
Installation
1.12 MFP EXPANSION
CAUTION
The controller box and the fax unit contain lithium batteries. The danger of
explosion exists if a battery of this type is incorrectly replaced. Replace
only with the same or an equivalent type recommended by the
manufacturer. Discard batteries in accordance with the manufacturer’s
instructions and local regulations.
This section (1.12) includes the installation procedures for the optional controller
box, optional printer scanner, and optional fax. See each step as necessary.
Reference
Machine Configuration
Component Panel and Key Settings
Printer/scanner
Steps 1 → 2 → 5 Steps 6 → 7
Steps 10
Printer/scanner + PostScript 3
Steps 1 → 2 → 3 → 5 Steps 6 → 7
Steps 10
Fax
Steps 1 → 4 → 5 Steps 6 → 8 Steps 10 → 11
Printer/scanner + Fax
Steps 1 → 2 → 4 → 5 Steps 6 → 9 Steps 10 → 11
Printer/scanner + PostScript 3 + Fax
Steps 1 → 2 → 3 → 4 → 5 Steps 6 → 9 Steps 10 → 11
