Ricoh B121 - Drive Layout

OVERVIEW
B121 Series/B259 Series 6-4 SM
6.1.3 DRIVE LAYOUT
1. Scanner Motor
2. Main Motor
3. Hot Roller
4. OPC Drum
5. Development Roller
6. Relay Clutch
7. Lower Paper Feed Clutch
8. By-pass Feed Clutch
9. Upper Paper Feed Clutch
10. Registration Clutch
B121D925.WMF
B121D926.WMF
1
2
3
4
5
7
8
9
6
10
