SERVICE PROGRAM MODE
B121 Series/B259 Series 5-28 SM
1007
Display By-pass
1007 1 Display By-pass Displays the by-pass paper width switch output.
Fusing Idling
1103*
Selects whether or not fusing idling is performed. Normally disabled in this machine.
However, enable this mode if fusing is incomplete on the 1st and 2nd copies, which
may occur if the room is cold.
1103 1 Fusing Idling [0 = No / 1 = Yes]
Fusing Temperature Adjustment
1105*
Adjusts the target fusing temperature. "Center" indicates the center of the roller;
"End" indicates the front and rear ends.
1105 1 Warm Up-Center
1105 2 Warm Up-End
[140 ~ 180 / 160 / 1°C/step]
1105 3 Standby-Center [140 ~ 170 / 155 / 1°C/step]
1105 4 Standby-End [140 ~ 165 / 150 / 1°C/step]
1105 5 Copying-Center
1105 6 Copying-End
[140 ~ 185 / 160 / 1°C/step]
1105 7 Low Level 2-Center
1105 8 Low Level 2-End
[0 ~ 80 / 60 / 1°C/step]
1105 9 Thick-Center
1105 10 Thick-End
[140 ~ 185 / 175 / 1°C/step]
1105 11 Warm Up Low-Center
1105 12 Warm Up Low-End
[140 ~ 180 / 170 / 1°C/step]
1106
Display Fusing
1106 1 Display Fusing (Center)
1106 2 Display Fusing (End)
Displays the fusing temperature on the center or on
the ends of the hot roller.
Fusing Soft Start
1107*
Adjusts the number of zero-cross cycles of the fusing lamp AC supply needed to
bring the fusing lamp power to 100% while bringing the lamp up to the standby
temperature or while copying. Increase this value if the machine is experiencing
sudden power dropouts ( 6.13.5).
1107 1 Warm Up Soft Start [0 = 10 cycles / 1 = 20 cycles / 2 = 50 cycles]
1107 2 Other Soft Start [0 = 5 cycles / 1 = 10 cycles / 2 = 20 cycles]
1108*
Set-Fusing Start [0 = 1s / 1 = 1.5s / 2 = 2s]
1108 1 Specifies the interval for fusing-temperature control ( 6.13.5).
1109
Nip Band Check
1109 1 Checks the fusing nip band ( 3.10.8).
