SERVICE PROGRAM MODE
SM 5-49 B121 Series/B259 Series
Service
Tables
5846* UCS Settings
Machine ID (For Delivery Server) Displays ID 5846 1*
Displays the unique device ID in use by the delivery server directory. The value is
only displayed and cannot be changed. This ID is created from the NIC MAC or
IEEE 1394 EUI. The ID is displayed as either 6-byle or 8-byte binary.
Machine ID Clear (For Delivery Server) Clears ID 5846 2*
Clears the unique ID of the device used as the name in the file transfer directory.
Execute this SP if the connection of the device to the delivery server is unstable.
After clearing the ID, the ID will be established again automatically by cycling the
machine off and on.
Maximum Entries [2000~50000/ 2000 /1] 5846 3*
Changes the maximum number of entries that UCS can handle.
If a value smaller than the present value is set, the UCS managed data is cleared,
and the data (excluding user code information) is displayed.
Delivery Server Model 0: Not used, 1:SG1 Provided,
2: SG1 Package, 3: SG2 Provided
4: SG2 Package
5846 4*
Changes the model of the transfer server registered for the I/O device.
Delivery Server Capability Bit 7 = 1 Comment information
Bit 6 = 1 Address direct entry possible
Bit 5 = 1 Mail Rx confirmation possible
Bit 4 = 1 Address book auto update
Bit 3 = 1 Fax Rx function
[0~255 / 0 / 2]
5846 5*
Changes the capability of the server registered for the I/O device.
Delivery Server Retry Timer [0~255/ 0 /1] 5846 6*
Sets the interval for retry attempts when the delivery server fails to acquire the
delivery server address book.
Delivery Server Retry Times [0~255/ 0 /1] 5846 7*
Sets the number of retry attempts when the delivery server fails to acquire the
delivery server address book.
Delivery Server Maximum Entries [2000~50000 / 2000 / 1] 5846 8*
Sets the maximum number account entries of the delivery server user information
managed by UCS.
5846 50* Initialize All Directory Info. Clears all directory information managed by UCS,
including all user codes.
5846 51* Upload All Directory Info. Uploads all directory information to the IC card.
5846 52* Download All Directory Info. Downloads all directory information from the IC
card.
5846 80* Backup FCU Backs up all directory information to the FCU
ROM.
5846 90* Plain Data Forbidden Allows you to prevent the address from plain data.
This is a security function that prevents
unauthorized access to address book data.
0: No check. Address book data not protected.
1: Check. Allows operation of UCS without data
from SC card and without creating address
book information with plain data.
SSP
5846 99*
Bit SW Sets UCS debug output. DFU
