SPECIFICATIONS
B121 Series/B259 Series 7-2 SM
Power Source: Taiwan
110 V, 60 Hz
12 A
Korea
220 V, 60 Hz
7 A
North and South America
120 V, 60 Hz
12 A
Europe, Asia
220 – 240 V, 50/60 Hz
7 A
Power Consumption:
Full System Not above 1.28 kW
Energy Saver Not above 10 W
Off Mode Not above 1 W
NOTE: Full system - Maximum possible power consumption (any combination of
mainframe and options), excluding optional heaters, key counter, fax unit,
and printer controller.
Noise Emission
Sound Power Level
Standby (Mainframe/Full
system):
Not above 40 dB(A)
Operating (Mainframe only): Not above 62 dB(A)
Operating (Full System): Not above 66 dB(A)
NOTE: The above measurements were made in accordance with ISO 7779.
Measurements were taken from the normal position of the operator.
Dimensions (W x D x H)
B121: 550 x 568 x 420 mm (21.7" x 22.4" x 16.5")
B122: 550 x 568 x 558 mm (21.7" x 22.4" x 23.0")
B123: 587 x 568 x 558 mm (23.1" x 22.4" x 23.0")
NOTE: Measurement Conditions
1) With bypass feed table closed
2) Without the A(R)DF
Weight
B121: 35 kg (77 lb.)
B122: 43 kg (95 lb.)
B123: 47 kg (103 lb.)
(Excluding A(R)DF, platen cover, toner, and developer)
