ORIGINAL SIZE DETECTION
SM 5 B387
Document
Feeder
B387
NA EU
Original
Length 1
Original
Length 2
P1 P2 P3 P4
1 A3 (297 x 420)
ON ON - - - ON
2 B4 (257 x 364)
ON ON - - ON -
3 A4 SEF (210 x 297)
ON - - ON - -
4 A4 LEF (297 x 210)
- - - - - ON
5 B5 SEF (182 x 257)
ON - ON - - -
6 B5 LEF (257 x 182)
- - - - ON -
7 A5 SEF (148 x 210)
- - ON - - -
8 A5 LEF (210 x 148)
- - - ON - -
9 11" x 17"
1
ON ON - - - ON
10 11" x 15"
1
ON ON - - - ON
11 10" x 14"
ON ON - - ON -
12 81/2" x 14"
2
ON ON - ON - -
13 81/2" x 13"
4
ON ON - ON - -
14 8" x 13"
2 4
ON ON - ON - -
15 81/2" x 11" SEF
3
ON - - ON - -
16 11" x 81/2" LEF
- - - - - ON
17 8" x 10" SEF
3
ON - - ON - -
18 51/2" x 81/2" SEF
- - ON - - -
19 81/2" x 51/2" LEF
- - - ON - -
NA: America (North, Middle, South) EU: Europe, Asia, China, Taiwan
: No : Yes ON: Paper present
1, 1: In NA, original size 11" x 15" is detected as 11" x 17"
2, 2: In NA, original size 8" x 13" is detected as 81/2" x 14"
3, 3: In NA, original size 8" x 10" is detected as 81/2" x 11"
4, 4: In EU, original size 8" x 13" is detected as 81/2" x 13"
- Original Width Sensor States -
Width Sensor 1 High Low Low High
Width Sensor 2 High High Low Low
Detection State P1 P2 P3 P4
Low = Blocked High = Open
