DEDICATED TRANSMISSION PARAMETERS
SM 63 B620
Fax Option
B620
Switch 02
No FUNCTION COMMENTS
0
to
3
Initial Tx modem rate
Bit 3 2 1 0 Setting (bps)
0 0 0 0 Not used
0 0 0 1 2,400
0 0 1 0 4,800
0 0 1 1 7,200
0 1 0 0 9,600
0 1 0 1 12,000
0 1 1 0 14,400
0 1 1 1 16,800
1 0 0 0 19,200
1 0 0 1 21,600
1 0 1 0 24,000
1 0 1 1 26,400
1 1 0 0 28,800
1 1 0 1 31,200
1 1 1 0 33,600
1 1 1 1 Disabled
Other settings: Not used
If training with a particular remote terminal always
takes too long, the initial modem rate may be too
high. Reduce the initial Tx modem rate using these
bits.
For the settings 14.4 or kbps slower, Switch 04 bit 4
must be changed to 0.
Note: Do not use settings other than listed on the
left.
If the setting is “Disabled”, the bit switch setting is
used.
4-5 Not used Do not change the settings.
6
AI short protocol
0: Off
1: Disabled
Refer to Appendix B in the Group 3 Facsimile
Manual for details about AI Short Protocol.
If the setting is “Disabled”, the bit switch setting is
used.
7 Not used Do not change the settings.
