Chapter 6 Protective Trip and Warning Functions
Current Trip Enable (Parameter 183) and Current Warning Enable (Parameter
189) are used to enable the respective current-based protective trip and warning
functions.
Table 158 - Current Trip Enable (Parameter 183)
Table 159 - Current Warning Enable (Parameter 189)
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X
Overload Trip
X
Phase Loss Trip
X
Ground Fault Trip
X
Stall Trip
X
Jam Trip
X
Underload Trip
X
Current Imbalance Trip
X
L1 Under Current Trip
X
L2 Under Current Trip
X
L3 Under Current Trip
X
L1 Over Current Trip
X
L2 Over Current Trip
X
L3 Over Current Trip
X
L1 Line Loss Trip
X
L2 Line Loss Trip
X
L3 Line Loss Trip
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X
Overload Warning
Reserved
X
Ground Fault Warning
Reserved
X
Jam Warning
X
Underload Warning
X
Current Imbalance Warning
X
L1 Under Current Warning
X
L2 Under Current Warning
X
L3 Under Current Warning
X
L1 Over Current Warning
X
L2 Over Current Warning
X
L3 Over Current Warning
X
L1 Line Loss Warning
X
L2 Line Loss Warning
X
L3 Line Loss Warning
