Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 131
Protective Trip and Warning Functions Chapter 6
Current Trip Status (Parameter 4) and Current Warning Status (Parameter 10)
are used to monitor the respective current-based protective trip and warning
functions.
Table 160 - Current Trip Status (Parameter 4)
Table 161 - Current Warning Status (Parameter 10)
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X
Overload Trip
X
Phase Loss Trip
X
Ground Fault Current Trip
X
Stall Trip
X
Jam Trip
X
Underload Trip
X
Current Imbalance Trip
X
L1 Under Current Trip
X
L2 Under Current Trip
X
L3 Under Current Trip
X
L1 Over Current Trip
X
L2 Over Current Trip
X
L3 Over Current Trip
X
L1 Line Loss Trip
X
L2 Line Loss Trip
X
L3 Line Loss Trip
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X
Overload Warning
Reserved
X
Ground Fault Warning
Reserved
X
Jam Warning
X
Underload Warning
X
Current Imbalance Warning
X
L1 Under Current Warning
X
L2 Under Current Warning
X
L3 Under Current Warning
X
L1 Over Current Warning
X
L2 Over Current Warning
X
L3 Over Current Warning
X
L1 Line Loss Warning
X
L2 Line Loss Warning
X
L3 Line Loss Warning
