Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 285
Protective Trip and Warning Functions Chapter 6
condition must be present before a trip occurs. It is adjustable from 0.1…25.0
seconds.
Table 343 - Analog Module 4 – Channel 00 Over Level Trip Delay (Parameter 536)
Analog Module 4 – Channel 00 Trip Level
Analog Module 4 – Channel 00 Trip Level (Parameter 537) allows you to define
the magnitude of the analog signal in which the E300 Electronic Overload Relay
trips on an Analog Module 4 – Channel 00 Over Level trip. It is user-adjustable
from -32768…+32767.
Table 344 - Analog Module 4 – Channel 00 Trip Level (Parameter 537)
Analog Module 4 – Channel 00 Over Level Warning
The E300 Electronic Overload Relay indicates an Analog Module 4 – Channel
00 Over Level warning if:
• No warning currently exists
• Analog Module 4 – Channel 00 Over Level Warning is enabled
• The maximum phase current is equal to or greater than the Analog
Module 3 – Channel 00 Warning Level
When the Analog Module 3 – Channel 00 Over Level Warning conditions are
satisfied, the:
• TRIP/WARN LED flashes a yellow 4-long / 10-short blink pattern
• Bit 9 in Analog Warning Status (Parameter 14) sets to 1
• Bit 1 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Warning Alarm closes
Analog Module 4 – Channel 00 Warning Level
Analog Module 4 – Channel 00 Warning Level (Parameter 538) allows you to
define the magnitude of the analog signal in which the E300 Electronic Overload
Default Value 1.0
Minimum Value 0.1
Maximum Value 25.0
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 10
Units Seconds
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
