286 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Relay trips on an Analog Module 4 – Channel 00 Over Level warning. It is user-
adjustable from -32768…+32767.
Table 345 - Analog Module 4 – Channel 00 Warning Level (Parameter 538)
Analog Module 4 – Channel 01 Over Level Trip
The E300 Electronic Overload Relay trips with an Analog Module 4 – Channel
01 Over Level Trip indication if:
• No trip currently exists
• Analog Module 4 – Channel 01 Over Level Trip is enabled
• The measured analog input signal is greater than the Analog Module 4 –
Channel 01 Trip Level for a time period greater than the Analog Module 4
– Channel 01 Over Level Trip Delay.
If the E300 Electronic Overload Relay trips on an Analog Module 4 – Channel
01 Over Level, the:
• TRIP/WARN LED status indicator flashes a red 4-long / 11-short blink
pattern
• Bit 10 in Analog Trip Status (Parameter 8) sets to 1
• Bit 0 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Trip Relay open
• Any relay outputs configured as a Control Relay open
• Any relay outputs configured as a Trip Alarm close
• Any relay outputs configured as a Normal Relay are placed in their
Protection Fault state (if so programmed)
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
