290 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 6 Protective Trip and Warning Functions
Table 349 - Analog Module 4 – Channel 02 Over Level Trip Delay (Parameter 554)
Analog Module 4 – Channel 02 Trip Level
Analog Module 4 – Channel 02 Trip Level (Parameter 555) allows you to define
the magnitude of the analog signal in which the E300 Electronic Overload Relay
trips on an Analog Module 4 – Channel 02 Over Level trip. It is user-adjustable
from -32768…+32767.
Table 350 - Analog Module 4 – Channel 02 Trip Level (Parameter 555)
Analog Module 4 – Channel 02 Over Level Warning
The E300 Electronic Overload Relay indicates an Analog Module 4 – Channel
02 Over Level warning if:
No warning currently exists
Analog Module 4 – Channel 02 Over Level Warning is enabled
The maximum phase current is equal to or greater than the Analog
Module 4 – Channel 02 Warning Level
When the Analog Module 4 – Channel 02 Over Level Warning conditions are
satisfied, the:
TRIP/WARN LED flashes a yellow 4-long / 12-short blink pattern
Bit 11 in Analog Warning Status (Parameter 14) sets to 1
Bit 1 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Warning Alarm close
Default Value 1.0
Minimum Value 0.1
Maximum Value 25.0
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 10
Units Seconds
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
