Rockwell Automation Publication 193-UM015D-EN-P - February 2015 291
Protective Trip and Warning Functions Chapter 6
Analog Module 4 – Channel 02 Warning Level
Analog Module 4 – Channel 02 Warning Level (Parameter 556) allows you to
define the magnitude of the analog signal in which the E300 Electronic Overload
Relay trips on an Analog Module 4 – Channel 02 Over Level warning. It is user-
adjustable from -32768…+32767.
Table 351 - Analog Module 4 – Channel 02 Warning Level (Parameter 556)
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
