EtherNet/IP Communications Chapter 9
3. Search for an E300 Electronic Overload Relay by typing E300 in the
search field, select the 193-ECM-ETR E300 Electronic Overload Relay, 2-
Port device profile, and press Create.
4. Type a name for the E300 Electronic Overload Relay, and press Change to
update the module definition.
5. Press Upload to read the configuration settings from the E300 Electronic
Overload Relay.
ATTENTION: If an Upload command is not performed, any preconfigured E300
Electronic Overload Relay configuration data will not be retained when
downloading an RSLogix 5000 or Studio 5000 project to a Logix controller or
when adding a new E300 Electronic Overload Relay online to a ControlLogix
project.
