Rockwell Automation Publication 193-UM015D-EN-P - February 2015 411
EtherNet/IP Communications Chapter 9
8. Configure the E300 Electronic Overload Relay system's Operating Mode
and associated relay output assignments. See
Chapter 5 for more
information about Operating Modes.
9. The E300 Electronic Overload Relay allows you to configure up to
eightDatalinks. Select the parameters for the additional data to be
included with the input tags. Press OK to complete the module definition.
10. Next, set the overload protection configuration parameters for your
specific motor application by selecting Protection.
