Rockwell Automation Publication 193-UM015D-EN-P - February 2015 415
EtherNet/IP Communications Chapter 9
1. Create a new or open an existing RSLogix 5000 or Studio 5000 project
and verify that the Logix controller is offline.
2. Right-click on the EtherNet/IP scanner within the I/O Configuration
folder, then select New Module to open the Select Module Type window.
3. Select the Generic Ethernet Module, then click Create.
