Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 463
Parameter List Appendix B
Device Monitor
(continued)
13 WarnStsControl
I.Protection.PTCWarning
I.Protection.ModuleMismatchWarning
I.Protection.ExpansionBusWarning
I.Protection.NumberOfStartsWarning
I.Protection.OperatingHoursWarning
Warning Status
bits for Control
UINT 2 1 BBit0= Reserved
Bit1= PTCWarning
Bit2= DLXWarning
Bit3= Reserved
Bit4= Reserved
Bit5= Reserved
Bit6= Reserved
Bit7= Reserved
Bit8= OptionMatchWarn
Bit9= DLXFBTimeoutWarn
Bit10= ExpansionBusWarn
Bit11= PMNumberOfStarts
Bit12= PMOperatingHours
0
14 WarnStsAnalog I.Protection.Analog1Ch00Warning
I.Protection.Analog1Ch01Warning
I.Protection.Analog1Ch02Warning
I.Protection.Analog2Ch00Warning
I.Protection.Analog2Ch01Warning
I.Protection.Analog2Ch02Warning
I.Protection.Analog3Ch00Warning
I.Protection.Analog3Ch01Warning
I.Protection.Analog3Ch02Warning
I.Protection.Analog4Ch00Warning
I.Protection.Analog4Ch01Warning
I.Protection.Analog4Ch02Warning
Warning Status
bits for Analog
UINT 2 1 Bit0= InAnMod1Ch00Warn
Bit1= InAnMod1Ch01Warn
Bit2= InAnMod1Ch02Warn
Bit3= InAnMod2Ch00Warn
Bit4= InAnMod2Ch01Warn
Bit5= InAnMod2Ch02Warn
Bit6= InAnMod3Ch00Warn
Bit7= InAnMod3Ch01Warn
Bit8= InAnMod3Ch02Warn
Bit9= InAnMod4Ch00Warn
Bit10= InAnMod4Ch01Warn
Bit11= InAnMod4Ch02Warn
0
15 Reserved
16 InputStatus0 I.Pt00Data
I.Pt01Data
I.Pt02Data
I.Pt03Data
I.Pt04Data
I.Pt05Data
Status of Digital
Inputs
UINT 2 1 Bit0= InputPt00
Bit1= InputPt01
Bit2= InputPt02
Bit3= InputPt03
Bit4= InputPt04
Bit5= InputPt05
0
17 InputStatus1 I.Digital1Pt00Data
I.Digital1Pt01Data
I.Digital1Pt02Data
I.Digital1Pt03Data
I.Digital2Pt00Data
I.Digital2Pt01Data
I.Digital2Pt02Data
I.Digital2Pt03Data
I.Digital3Pt00Data
I.Digital3Pt01Data
I.Digital3Pt02Data
I.Digital3Pt03Data
I.Digital4Pt00Data
I.Digital4Pt01Data
I.Digital4Pt02Data
I.Digital4Pt03Data
Status of Digital
Expansion Module
Inputs
UINT 2 1 Bit0= InputDigMod1Pt00
Bit1= InputDigMod1Pt01
Bit2= InputDigMod1Pt02
Bit3= InputDigMod1Pt03
Bit4= InputDigMod2Pt00
Bit5= InputDigMod2Pt01
Bit6= InputDigMod2Pt02
Bit7=1nputDigMod2Pt03
Bit8= InputDigMod3Pt00
Bit9= InputDigMod3Pt01
Bit10= InputDigMod3Pt02
Bit11= InputDigMod3Pt03
Bit12= InputDigMod4Pt00
Bit13= InputDigMod4Pt01
Bit14= InputDigMod4Pt02
Bit15= InputDigMod4Pt03
0
18 OutputStatus I.Pt00Readback
I.Pt01Readback
I.Pt02Readback
I.Digital1Pt00Readback
I.Digital1Pt01Readback
I.Digital2Pt00Readback
I.Digital2Pt01Readback
I.Digital3Pt00Readback
I.Digital3Pt01Readback
I.Digital4Pt00Readback
I.Digital4Pt01Readback
Status of Digital
Outputs
UINT 2 1 Bit0= OutputPt00
Bit1= OutputPt01
Bit2= OutputPt02
Bit3= OutDigMod1Pt00
Bit4= OutDigMod1Pt01
Bit5= OutDigMod2Pt00
Bit6= OutDigMod2Pt01
Bit7= OutDigMod3Pt00
Bit8= OutDigMod3Pt01
Bit9= OutDigMod4Pt00
Bit10= OutDigMod4Pt01
0
19 OpStationStatus I.OperatorStationI
I.OperatorStationII
I.OperatorStationLocalRemote
I.OperatorStationO
I.OperatorStationReset
I.OperatorStationILEDReadback
I.OperatorStationIILEDReadback
I.OperatorStationLocalLEDReadback
I.OperatorStationRemoteLEDReadback
I.OperatorStationOLEDReadback
Status of Operator
Station Buttons
and LEDs
UINT 2 1 Bit0= OpStationStart1
Bit1= OpStationStart2
Bit2= OSLocalRemote
Bit3= OpStationStop
Bit4= OpStationReset
Bit5= Reserved
Bit6= Reserved
Bit7= Reserved
Bit8= OSLED1Green
Bit9= OSLED2Green
Bit10= OSLED3Amber
Bit11= OSLED3Red
Bit12= OSLED4Red
0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
