464 Rockwell Automation Publication 193-UM015D-EN-P - November 2013
Appendix B Parameter List
Device Monitor
(continued)
20 DeviceStatus0 I.TripPresent
I.WarningPresent
I.InvalidConfiguration
I.MotorCurrentPresent
I.GroundFaultCurrentPresent
I.MotorVoltagePresent
I.EmergencyStartEnabled
I.DeviceLogixEnabled
I.FeedbackTimeoutEnabled
I.OperatorStationPresent
I.VoltageSensingPresent
I.InternalGroundFaultSensingPresent
I.ExternalGroundFaultSensingPresent
I.PTCSensingPresent
I.Ready
Device Status bits UINT 2 1 Bit0= TripPresent
Bit1= WarningPresent
Bit2= InvalidConfig
Bit3= CurrentPresent
Bit4= GFCurrentPresent
Bit5= VoltagePresent
Bit6= EmergencyStartEn
Bit7= DeviceLogixEn
Bit8= FeebckTimeoutEn
Bit9= OperatorStation
Bit10= VoltageSensing
Bit11= InternGFSensing
Bit12= ExternGFSensing
Bit13= PTCSensing
Bit14= Ready
Bit 15=Admin Mode Active
0
21 DeviceStatus1 I.ContolModule24VDCPresent
I.ControlModule120VACPresent
I.ControlModule240VACPresent
I.SensingModule30APresent
I.SensingModule60APresent
I.SensingModule100APresent
I.SensingModule200APresent
I.DigitalModule1Present
I.DigitalModule2Present
I.DigitalModule3Present
I.DigitalModule4Present
I.AnalogModule1Present
I.AnalogModule2Present
I.AnalogModule3Present
I.AnalogModule4Present
Device Status bits UINT 2 1 Bit0= 24VoltControl
Bit1= 120VoltControl
Bit2= 240VoltControl
Bit3= CurrentSense30A
Bit4= CurrentSense60A
Bit5= CurrentSense100A
Bit6= CurrentSense200A
Bit7= DigitalModule1
Bit8= DigitalModule2
Bit9= DigitalModule3
Bit10= DigitalModule4
Bit11= AnalogModule1
Bit12= AnalogModule2
Bit13= AnalogModule3
Bit14= AnalogModule4
0
22 Firmware Firmware Revision
Number
UINT 2 1000 0 65535 1001
23 ControlModuleID Control Module
Type Detected
USINT 1 1 0= Unknown
1= 6In3Out24VDC
2= 4In3Out120VAC
3= 4In3Out240VAC
4= 4In2OutGFPTC24V
5= 2In2OutGFPTC120V
6= 2In2OutGFPTC240V
0
24 SensingModuleID Sensing Module
Types Detected
USINT 1 1 0= Unknown
1= VIGPt5to30Amp
2= VIG6to60Amp
3= VIG10to100Amp
4= VIG20to200Amp
5= IGPt5to30Amp
6= IG6to60Amp
7= IG10to100Amp
8= IG20to200Amp
9= IPt5to30Amp
10= I6to60Amp
11= I10to100Amp
12= I20to200Amp
0
25 OperStationID Operator Station
Types Detected
USINT 1 1 0= Unknown
1= NoStation
2= ControlStation
3= DiagStation
0
26 DigitalModuleID Expansion Digital
Module Types
Detected
UINT 2 1 Bit0= DigitalMod1[0]
Bit1= DigitalMod1[1]
Bit2= DigitalMod1[2]
Bit3= DigitalMod2[0]
Bit4= DigitalMod2[1]
Bit5= DigitalMod2[2]
Bit6= DigitalMod3[0]
Bit7= DigitalMod3[1]
Bit8= DigitalMod3[2]
Bit9= DigitalMod4[0]
Bit10= DigitalMod4[1]
Bit11= DigitalMod4[2]
0
27 AnalogModuleID Expansion Bus
Analog Module
Typ es
UINT 2 1 Bit0= AnalogMod1[0]
Bit1= AnalogMod1[1]
Bit2= AnalogMod2[0]
Bit3= AnalogMod2[1]
Bit4= AnalogMod3[0]
Bit5= AnalogMod3[1]
Bit6= AnalogMod4[0]
Bit7= AnalogMod4[1]
0
28 OperatingTime Time unit has been
powered on
UINT 2 1 0 65535 0 Hrs
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
