Rockwell Automation Allen-Bradley E300

468 Rockwell Automation Publication 193-UM015D-EN-P - November 2013
Appendix B Parameter List
Analog Monitoring 111 InAnMod1Ch00 I.Analog1.Ch00Data Value measured at
Analog Expansion
Module 1 Input 00
UINT 2 1 -32768 32767 0
112 InAnMod1Ch01 I.Analog1.Ch01Data Value measured at
Analog Expansion
Module 1 Input 01
UINT 2 1 -32768 32767 0
113 InAnMod1Ch02 I.Analog1.Ch02Data Value measured at
Analog Expansion
Module 1 Input 02
UINT 2 1 -32768 32767 0
114 InAnMod2Ch00 I.Analog2.Ch00Data Value measured at
Analog Expansion
Module 2 Input 00
UINT 2 1 -32768 32767 0
115 InAnMod2Ch01 I.Analog2.Ch01Data Value measured at
Analog Expansion
Module 2 Input 01
UINT 2 1 -32768 32767 0
116 InAnMod2Ch02 I.Analog2.Ch02Data Value measured at
Analog Expansion
Module 2 Input 02
UINT 2 1 -32768 32767 0
117 InAnMod3Ch00 I.Analog3.Ch00Data Value measured at
Analog Expansion
Module 3 Input 00
UINT 2 1 -32768 32767 0
118 InAnMod3Ch01 I.Analog3.Ch01Data Value measured at
Analog Expansion
Module 3 Input 01
UINT 2 1 -32768 32767 0
119 InAnMod3Ch02 I.Analog3.Ch02Data Value measured at
Analog Expansion
Module 3 Input 02
UINT 2 1 -32768 32767 0
120 InAnMod4Ch00 I.Analog4.Ch00Data Value measured at
Analog Expansion
Module 4 Input 00
UINT 2 1 -32768 32767 0
121 InAnMod4Ch01 I.Analog4.Ch01Data Value measured at
Analog Expansion
Module 4 Input 01
UINT 2 1 -32768 32767 0
122 InAnMod4Ch02 I.Analog4.Ch02Data Value measured at
Analog Expansion
Module 4 Input 02
UINT 2 1 -32768 32767 0
123 AnalogMod1Status I.Analog1.Ch00InputOpenWire
I.Analog1.Ch00InputOverrange
I.Analog1.Ch00InputUnderrange
I.Analog1.Ch01InputOpenWire
I.Analog1.Ch01InputOverrange
I.Analog1.Ch01InputUnderrange
I.Analog1.Ch02InputOpenWire
I.Analog1.Ch02InputOverrange
I.Analog1.Ch02InputUnderrange
I.Analog1.Ch00OutputOpenWire
I.Analog1.Ch00OutputInHold
I.Analog1.Ch00OutputOverrange
I.Analog1.Ch00OutputUnderrange
I.Analog1.AddressChanged
I.Analog1.SelftestFailed
Analog Expansion
Module 1 Status
UINT 2 1 Bit0= InCh00OpenCrcuit
Bit1= InCh00OverRange
Bit2= InCh00UnderRange
Bit3= InCh01OpenCrcuit
Bit4= InCh01OverRange
Bit5= InCh01UnderRange
Bit6= InCh02OpenCrcuit
Bit7= InCh02OverRange
Bit8= InCh02UnderRange
Bit9= OutOpenCircuit
Bit10= OutHoldLastSt
Bit11= OutOverRange
Bit12= OutUnderRange
Bit 13=Module Configured
Bit 14=Module Warning
Bit 15=Module Faulted
0
124 AnalogMod2Status I.Analog3.Ch00InputOpenWire
I.Analog3.Ch00InputOverrange
I.Analog3.Ch00InputUnderrange
I.Analog3.Ch01InputOpenWire
I.Analog3.Ch01InputOverrange
I.Analog3.Ch01InputUnderrange
I.Analog3.Ch02InputOpenWire
I.Analog3.Ch02InputOverrange
I.Analog3.Ch02InputUnderrange
I.Analog3.Ch00OutputOpenWire
I.Analog3.Ch00OutputInHold
I.Analog3.Ch00OutputOverrange
I.Analog3.Ch00OutputUnderrange
I.Analog3.AddressChanged
I.Analog3.SelftestFailed
Analog Expansion
Module 2 Status
UINT 2 1 Bit0= InCh00OpenCrcuit
Bit1= InCh00OverRange
Bit2= InCh00UnderRange
Bit3= InCh01OpenCrcuit
Bit4= InCh01OverRange
Bit5= InCh01UnderRange
Bit6= InCh02OpenCrcuit
Bit7= InCh02OverRange
Bit8= InCh02UnderRange
Bit9= OutOpenCircuit
Bit10= OutHoldLastSt
Bit11= OutOverRange
Bit12= OutUnderRange
Bit 13=Module Configured
Bit 14=Module Warning
Bit 15=Module Faulted
0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
