Rockwell Automation Publication 193-UM015D-EN-P - February 2015 469
Parameter List Appendix B
Analog Monitoring
(Continued)
125 AnalogMod3Status I.Analog3.Ch00InputOpenWire
I.Analog3.Ch00InputOverrange
I.Analog3.Ch00InputUnderrange
I.Analog3.Ch01InputOpenWire
I.Analog3.Ch01InputOverrange
I.Analog3.Ch01InputUnderrange
I.Analog3.Ch02InputOpenWire
I.Analog3.Ch02InputOverrange
I.Analog3.Ch02InputUnderrange
I.Analog3.Ch00OutputOpenWire
I.Analog3.Ch00OutputInHold
I.Analog3.Ch00OutputOverrange
I.Analog3.Ch00OutputUnderrange
I.Analog3.AddressChanged
I.Analog3.SelftestFailed
Analog Expansion
Module 3 Status
UINT 2 1 Bit0= InCh00OpenCrcuit
Bit1= InCh00OverRange
Bit2= InCh00UnderRange
Bit3= InCh01OpenCrcuit
Bit4= InCh01OverRange
Bit5= InCh01UnderRange
Bit6= InCh02OpenCrcuit
Bit7= InCh02OverRange
Bit8= InCh02UnderRange
Bit9= OutOpenCircuit
Bit10= OutHoldLastSt
Bit11= OutOverRange
Bit12= OutUnderRange
Bit 13=Module Configured
Bit 14=Module Warning
Bit 15=Module Faulted
0
126 AnalogMod4Status I.Analog4.Ch00InputOpenWire
I.Analog4.Ch00InputOverrange
I.Analog4.Ch00InputUnderrange
I.Analog4.Ch01InputOpenWire
I.Analog4.Ch01InputOverrange
I.Analog4.Ch01InputUnderrange
I.Analog4.Ch02InputOpenWire
I.Analog4.Ch02InputOverrange
I.Analog4.Ch02InputUnderrange
I.Analog4.Ch00OutputOpenWire
I.Analog4.Ch00OutputInHold
I.Analog4.Ch00OutputOverrange
I.Analog4.Ch00OutputUnderrange
I.Analog4.AddressChanged
I.Analog4.SelftestFailed
Analog Expansion
Module 4 Status
UINT 2 1 Bit0= InCh00OpenCrcuit
Bit1= InCh00OverRange
Bit2= InCh00UnderRange
Bit3= InCh01OpenCrcuit
Bit4= InCh01OverRange
Bit5= InCh01UnderRange
Bit6= InCh02OpenCrcuit
Bit7= InCh02OverRange
Bit8= InCh02UnderRange
Bit9= OutOpenCircuit
Bit10= OutHoldLastSt
Bit11= OutOverRange
Bit12= OutUnderRange
Bit 13=Module Configured
Bit 14=Module Warning
Bit 15=Module Faulted
0
Trip/Warn History 127 TripHistory0 Last trip to occur UINT 2 1 See Trip History Codes 0
128 TripHistory1 Second last trip to
occur
UINT 2 1 See Trip History Codes 0
129 TripHistory2 Third last trip to
occur
UINT 2 1 See Trip History Codes 0
130 TripHistory3 Fourth last trip to
occur
UINT 2 1 See Trip History Codes 0
131 TripHistory4 Fifth last trip to
occur
UINT 2 1 See Trip History Codes 0
132 Reserved
133 WarningHistory0 Last warning to
occur.
UINT 2 1 See Warning History Codes 0
134 WarningHistory1 Second last
warning to occur.
UINT 2 1 See Warning History Codes 0
135 WarningHistory2 Third last warning
to occur.
UINT 2 1 See Warning History Codes 0
136 WarningHistory3 Fourth last
warning to occur.
UINT 2 1 See Warning History Codes 0
137 WarningHistory4 Fifth last warning
to occur.
UINT 2 1 See Warning History Codes 0
138 Reserved
139 TripHistoryMaskI C.History.OverloadTripEnEn
C.History.PhaseLossTripEn
C.History.GroundFaultCurrentTripEn
C.History.StallTripEn
C.History.JamTripEn
C.History.UnderloadTripEn
C.History.CurrentImbalanceTripEn
C.History.L1UnderCurrentTripEn
C.History.L2UnderCurrentTripEn
C.History.L3UnderCurrentTripEn
C.History.L1OverCurrentTripEn
C.History.L2OverCurrentTripEn
C.History.L3OverCurrentTripEn
C.History.L1LineLossTripEn
C.History.L2LineLossTripEn
C.History.L3LineLossTripEn
Trip History Mask
for Current-based
Trips
UINT 2 1 Bit0= OverloadTrip
Bit1= PhaseLossTrip
Bit2= GroundFaultTrip
Bit3= StallTrip
Bit4= JamTrip
Bit5= UnderloadTrip
Bit6= CurrentImbalTrip
Bit7= L1UnderCurrTrip
Bit8= L2UnderCurrTrip
Bit9= L3UnderCurrTrip
Bit10= L1OverCurrenTrip
Bit11= L2OverCurrenTrip
Bit12= L3OverCurrenTrip
Bit13= L1LineLossTrip
Bit14= L2LineLossTrip
Bit15= L3LineLossTrip
0xFFFF
140 TripHistoryMaskV C.History.UnderVoltageTripEn
C.History.OverVoltageTripEn
C.History.VoltageImbalanceTripEn
C.History.PhaseRotationMismatchTripEn
C.History.UnderFrequencyTripEn
C.History.OverFrequencyTripEn
Trip History Mask
for Voltage-based
Trips
UINT 2 1 Bit0= UnderVoltageTrip
Bit1= OvervoltageTrip
Bit2= VoltageUnbalTrip
Bit3= PhaseRotationTrp
Bit4= UnderFreqTrip
Bit5= OverFreqTrip
0x3F
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
