Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 483
Parameter List Appendix B
Output Setup
Continued
330 OutDig2ComFltAct C.Digital2FaultMode Digital Expansion
Module 2 Outputs
action on comms
fault
BOOL 1 1 0= GoToCommFltValue
1= HoldLastState
0
331 OutDig2ComFltVal C.Digital2FaultValue Digital Expansion
Module 2 Outputs
value on comms
fault
BOOL 1 1 0=Open
1=Closed
0
332 OutDig2ComIdlAct C.Digital2ProgMode Digital Expansion
Module 2 Outputs
action on comms
idle
BOOL 1 1 0= GoToCommIdlValue
1= HoldLastState
0
333 OutDig2ComIdlVal C.Digital2ProgValue Digital Expansion
Module 2 Outputs
value on comms
idle
BOOL 1 1 0=Open
1=Closed
0
334 OutDig3PrFltAct C.Digital3ProtectionFaultMode Digital Expansion
Module 3 Outputs
action on
protection fault
BOOL 1 1 0= GoToPrFltValue
1= Ignore
0
335 OutDig3PrFltVal C.Digital3ProtectionFaultValue Digital Expansion
Module 3 Outputs
value on
protection fault
BOOL 1 1 0=Open
1=Closed
0
336 OutDig3ComFltAct C.Digital3FaultMode Digital Expansion
Module 3 Outputs
action on comms
fault
BOOL 1 1 0= GoToCommFltValue
1= HoldLastState
0
337 OutDig3ComFltVal C.Digital3FaultValue Digital Expansion
Module 3 Outputs
value on comms
fault
BOOL 1 1 0=Open
1=Closed
0
338 OuDig3ComIdlAct C.Digital3ProgMode Digital Expansion
Module 3 Outputs
action on comms
idle
BOOL 1 1 0= GoToCommIdlValue
1= HoldLastState
0
339 OutDig3ComIdlVal C.Digital3ProgValue Digital Expansion
Module 3 Outputs
value on comms
idle
BOOL 1 1 0=Open
1=Closed
0
340 OutDig4PrFltAct C.Digital4ProtectionFaultMode Digital Expansion
Module 4 Outputs
action on
protection fault
BOOL 1 1 0= GoToPrFltValue
1= Ignore
0
341 OutDig4PrFltVal C.Digital4ProtectionFaultValue Digital Expansion
Module 4 Outputs
value on
protection fault
BOOL 1 1 0=Open
1=Closed
0
342 OutDig4ComFltAct C.Digital4FaultMode Digital Expansion
Module 4 Outputs
action on comms
fault
BOOL 1 1 0= GoToCommFltValue
1= HoldLastState
0
343 OutDig4ComFltVal C.Digital4FaultValue Digital Expansion
Module 4 Outputs
value on comms
fault
BOOL 1 1 0=Open
1=Closed
0
344 OutDig4ComIdlAct C.Digital4ProgMode Digital Expansion
Module 4 Outputs
action on comms
idle
BOOL 1 1 0= GoToCommIdlValue
1= HoldLastState
0
345 OutDig4ComIdlVal C.Digital4ProgValue Digital Expansion
Module 4 Outputs
value on comms
idle
BOOL 1 1 0=Open
1=Closed
0
DeviceLogix Setup
346 CommOverride Enabling allows
local logic to
override a loss of
an I/O Connection.
BOOL 1 1 0=Disable
1=Enable
0
347 NetworkOverride Enabling allows
local logic to
override a Network
Fault.
BOOL 1 1 0=Disable
1=Enable
0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
