Appendix B Parameter List
DeviceLogix Setup
(Continued)
348 PtDeviceOuts Status of
DeviceLogix
Network Outputs.
UINT 2 1 Bit0= Pt00DeviceOut
Bit1= Pt01DeviceOut
Bit2= Pt02DeviceOut
Bit3= Pt03DeviceOut
Bit4= Pt04DeviceOut
Bit5= Pt05DeviceOut
Bit6= Pt06DeviceOut
Bit7= Pt07DeviceOut
Bit8= Pt08DeviceOut
Bit9= Pt09DeviceOut
Bit10= Pt10DeviceOut
Bit11= Pt11DeviceOut
Bit12= Pt12DeviceOut
Bit13= Pt13DeviceOut
Bit14= Pt14DeviceOut
Bit15= Pt15DeviceOut
0
349 Reserved
350 PtDevOutCOSMask When bit is set the
network output
will trigger a COS
message.
UINT 2 1 Bit0= Pt00DeviceOut
Bit1= Pt01DeviceOut
Bit2= Pt02DeviceOut
Bit3= Pt03DeviceOut
Bit4= Pt04DeviceOut
Bit5= Pt05DeviceOut
Bit6= Pt06DeviceOut
Bit7= Pt07DeviceOut
Bit8= Pt08DeviceOut
Bit9= Pt09DeviceOut
Bit10= Pt10DeviceOut
Bit11= Pt11DeviceOut
Bit12= Pt12DeviceOut
Bit13= Pt13DeviceOut
Bit14= Pt14DeviceOut
Bit15= Pt15DeviceOut
0
351 DLXUserDefData General Purpose
Data Value for Use
in DeviceLogix
Programs
UDINT 4 1 0 0xFFFFFFFF 0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
