Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 485
Parameter List Appendix B
Voltage Setup 352 VoltageMode C.VoltageMode Voltage Wiring
Mode
USINT 1 1 0= Delta
1= Wye
2= DeltaPTDelta2Wye
3= WyePTDelta2Wye
4= DeltaPTWye2Delta
5= WyePTWye2Delta
0
353 PTPrimary C.PTPrimary Potential
Transformer
Primary Rating
UINT 2 1 1 65535 480
354 PTSecondary C.PTSecondary Potential
Transformer
Secondary Rating
UINT 2 1 1 540 480
355 UVInhibitTime C.UnderVoltageInhibitTime Under Voltage
Inhibit Time
USINT 1 1 0 250 10
Second
s
356 UVTripDelay C.UnderVoltageTripDelay Under Voltage Trip
Delay
USINT 1 10 1 250 10
Second
s
357 UVTripLevel C.UnderVoltageTripLimit Under Voltage Trip
Level
UINT 2 10 0 65535 1000 Volt
358 UVWarningLevel C.UnderVoltageWarnLimit Under Voltage
Warning Level
UINT 2 10 0 65535 4000 Volt
359 OVInhibitTime C.OverVoltageInhibitTime Over Voltage
Inhibit Time
USINT 1 1 0 250 10
Second
s
360 OVTripDelay C.OverVoltageTripDelay Over Voltage Trip
Delay
USINT 1 10 1 250 10
Second
s
361 OVTripLevel C.OverVoltageTripLimit Over Voltage Trip
Level
UINT 2 10 0 65535 5000 Volt
362 OVWarningLevel C.OverVoltageWarnLimit Over Voltage
Warning Level
UINT 2 10 0 65535 4900 Volt
363 PhRotInhibitTime C.PhaseRotationInhibitTime Phase Rotation
Inhibit Time
USINT 1 1 0 250 10
Second
s
364 PhaseRotTripType C.PhaseRotationTripType_0
C.PhaseRotationTripType_1
Voltage Phase
Rotation Trip Type
USINT 1 1 1 0=
NoRotation
1= ABC
2= ACB
1
365 VIBInhibitTime C.VoltageImbalanceInhibitTime Voltage Imbalance
Inhibit Time
USINT 1 1 0 250 10
Second
s
Voltage Setup
(continued)
366 VIBTripDelay C.VoltageImbalanceTripDelay Voltage Imbalance
Trip Delay
USINT 1 10 1 250 10
Second
s
367 VIBTripLevel C.VoltageImbalanceTripLimit Voltage Imbalance
Trip Level
USINT 1 1 0 100 85 %
368 VIBWarningLevel C.VoltageImbalanceWarnLimit Voltage Imbalance
Warning Level
USINT 1 1 0 100 75 %
369 UFInhibitTime C.UnderFrequencyInhibitTime Under Frequency
Inhibit Time
USINT 1 1 0 250 10
Second
s
370 UFTripDelay C.UnderFrequencyTripDelay Under Frequency
Trip Delay
USINT 1 10 1 250 10
Second
s
371 UFTripLevel C.UnderFrequencyTripLimit Under Frequency
Trip Level
USINT 1 1 46 65 57 Hz
372 UFWarningLevel C.UnderFrequencyWarnLimit Under Frequency
Warning Level
USINT 1 1 46 65 58 Hz
373 OFInhibitTime C.OverFrequencyInhibitTime Over Frequency
Inhibit Time
USINT 1 1 0 250 10
Second
s
374 OFTripDelay C.OverFrequencyTripDelay Over Frequency
Trip Delay
USINT 1 10 1 250 10
Second
s
375 OFTripLevel C.OverFrequencyTripLimit Over Frequency
Trip Level
USINT 1 1 46 65 63 Hz
376 OFWarningLevel C.OverFrequencyWarnLimit Over Frequency
Warning Level
USINT 1 1 46 65 62 Hz
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
