Rockwell Automation Allen-Bradley E300

488 Rockwell Automation Publication 193-UM015D-EN-P - November 2013
Appendix B Parameter List
Power Setup
(Continued)
413 UPFLagWarnLevel C.UnderPowerFactorLaggingWarnLimit Under Total Power
Factor Lagging (-
PF) Warning Level
SINT 1 1 -100 0 -95 %
414 OPFLagInhibTime C.OverPowerFactorLaggingInhibitTime Over Total Power
Factor Lagging (-
PF) Inhibit Time
USINT 1 1 0 250 10
Second
s
415 OPFLagTripDelay C.OverPowerFactorLaggingTripDelay Over Total Power
Factor Lagging (-
PF) Trip Delay
USINT 1 10 1 250 10
Second
s
416 OPFLagTripLevel C.OverPowerFactorLaggingTripLimit Over Total Power
Factor Lagging (-
PF) Trip Level
SINT 1 1 -100 0 -95 %
417 OPFLagWarnLevel C.OverPowerFactorLaggingWarnLimit Over Total Power
Factor Lagging (-
PF) Warning Level
SINT 1 1 -100 0 -90 %
418 UPFLeadInhibTime C.UnderPowerFactorLeadingInhibitTime Under Total Power
Factor Leading
(+PF) Inhibit Time
USINT 1 1 0 250 10
Second
s
419 UPFLeadTripDelay C.UnderPowerFactorLeadingTripDelay Under Total Power
Factor Leading
(+PF) Trip Delay
USINT 1 10 1 250 10
Second
s
420 UPFLeadTripLevel C.UnderPowerFactorLeadingTripLimit Under Total Power
Factor Leading
(+PF) Trip Level
USINT 1 1 0 100 90 %
421 UPFLeadWarnLevel C.UnderPowerFactorLeadingWarnLimit Under Total Power
Factor Leading
(+PF) Warning
Level
USINT 1 1 0 100 95 %
422 OPFLeadInhibTime C.OverPowerFactorLeadingInhibitTime Over Total Power
Factor Leading
(+PF) Inhibit Time
USINT 1 1 0 250 10
Second
s
423 OPFLeadTripDelay C.OverPowerFactorLeadingTripDelay Over Total Power
Factor Leading
(+PF) Trip Delay
USINT 1 10 1 250 10
Second
s
424 OPFLeadTripLevel C.OverPowerFactorLeadingTripLimit Over Total Power
Factor Leading
(+PF) Trip Level
USINT 1 1 0 100 95 %
425 OPFLeadWarnLevel C.OverPowerFactorLeadingWarnLimit Over Total Power
Factor Leading
(+PF) Warning
Level
USINT 1 1 0 100 90 %
426 DemandPeriod C.DemandPeriod The number of
minutes in a
specific demand
period
USINT 1 1 1 255 15 Min
427 NumberOfPeriods C.NumberOfDemandPeriods The number of
periods to average
for the demand
calculation
USINT 1 1 1 15 1
Diagnostic Display
Setup
428 Screen1Param1 C.Screen1ParameterSelect1 Parameter to
display on
Operator Station
Startup screen 1
line 1
UINT 2 1 0 560 1
429 Screen1Param2 C.Screen1ParameterSelect2 Parameter to
display on
Operator Station
Startup screen 1
line 2
UINT 2 1 0 560 50
430 Screen2Param1 C.Screen2ParameterSelect1 Parameter to
display on
Operator Station
Startup screen 2
line 1
UINT 2 1 0 560 2
431 Screen2Param2 C.Screen2ParameterSelect2 Parameter to
display on
Operator Station
Startup screen 2
line 2
UINT 2 1 0 560 3
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
