Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 487
Parameter List Appendix B
Power Setup
(Continued)
392 OVARCTripLevel C.OverReactivePowerConsumedTripLimit Over Total Reactive
Power Consumed
(+kVAR) Trip Level
DINT 4 1000 0 2000000000 0 kVAR
393 OVARCWarnLevel C.OverReactivePowerConsumedWarnLimit Over Total Reactive
Power Consumed
(+kVAR) Warning
Level
DINT 4 1000 0 2000000000 0 kVAR
394 UVARGInhibitTime C.UnderReactivePowerGeneratedInhibitTime Under Total
Reactive Power
Generated (-kVAR)
Inhibit Time
USINT 1 1 0 250 10
Second
s
395 UVARGTripDelay C.UnderReactivePowerGeneratedTripDelay Under Total
Reactive Power
Generated (-kVAR)
Trip Delay
USINT 1 10 1 250 10
Second
s
396 UVARGTripLevel C.UnderReactivePowerGeneratedTripLimit Under Total
Reactive Power
Generated (-kVAR)
Trip Level
DINT 4 1000 -2000000000 0 0 kVAR
397 UVARGWarnLevel C.UnderReactivePowerGeneratedWarnLimit Under Total
Reactive Power
Generated (-kVAR)
Warning Level
DINT 4 1000 -2000000000 0 0 kVAR
398 OVARGInhibitTime C.OverReactivePowerGeneratedInhibitTime Over Total Reactive
Power Generated
(-kVAR) Inhibit
Time
USINT 1 1 0 250 10
Second
s
399 OVARGTripDelay C.OverReactivePowerGeneratedTripDelay Over Total Reactive
Power Generated
(-kVAR) Trip Delay
USINT 1 10 1 250 10
Second
s
400 OVARGTripLevel C.OverReactivePowerGeneratedTripLimit Over Total Reactive
Power Generated
(-kVAR) Trip Level
DINT 4 1000 -2000000000 0 0 kVAR
401 OVARGWarnLevel C.OverReactivePowerGeneratedWarnLimit Over Total Reactive
Power Generated
(-kVAR) Warning
Level
DINT 4 1000 -2000000000 0 0 kVAR
402 UVAInhibitTime C.UnderApparentPowerInhibitTime Under Total
Apparent Power
Inhibit Time
USINT 1 1 0 250 10
Second
s
403 UVATripDelay C.UnderApparentPowerTripDelay Under Total
Apparent Power
Trip Delay
USINT 1 10 1 250 10
Second
s
404 UVATripLevel C.UnderApparentPowerTripLimit Under Total
Apparent Power
Trip Level
DINT 4 1000 0 2000000000 0 kVA
405 UVAWarningLevel C.UnderApparentPowerWarnLimit Under Total
Apparent Power
Warning Level
DINT 4 1000 0 2000000000 0 kVA
406 OVAInhibitTime C.OverApparentPowerInhibitTime Over Total
Apparent Power
Inhibit Time
USINT 1 1 0 250 10
Second
s
407 OVATripDelay Over Total
Apparent Power
Trip Delay
USINT 1 10 1 250 10
Second
s
408 OVATripLevel C.OverApparentPowerTripDelay Over Total
Apparent Power
Trip Level
DINT 4 1000 0 2000000000 0 kVA
409 OVAWarningLevel C.OverApparentPowerWarnLimit Over Total
Apparent Power
Warning Level
DINT 4 1000 0 2000000000 0 kVA
410 UPFLagInhibTime C.UnderPowerFactorLaggingInhibitTime Under Total Power
Factor Lagging (-
PF) Inhibit Time
USINT 1 1 0 250 10
Second
s
411 UPFLagTripDelay C.UnderPowerFactorLaggingTripDelay Under Total Power
Factor Lagging (-
PF) Trip Delay
USINT 1 10 1 250 10
Second
s
412 UPFLagTripLevel C.UnderPowerFactorLaggingTripLimit Under Total Power
Factor Lagging (-
PF) Trip Level
SINT 1 1 -100 0 -90 %
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
