Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 491
Parameter List Appendix B
Analog1 Setup
(Continued)
455 InAnMod1Ch02Type C.Analog1.Ch02InputRangeType_0
C.Analog1.Ch02InputRangeType_1
C.Analog1.Ch02InputRangeType_2
C.Analog1.Ch02InputRangeType_3
C.Analog1.Ch02InputRangeType_4
Assignment for
Analog Module 1
Input Channel 02
function
USINT 1 1 0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4= 1To5Volts
5= 0To5Volts
6= 100Pt385
7= 200Pt385
8= 500Pt385
9= 1000Pt385
10=100Pt3916
11= 200Pt3916
12= 500Pt3916
13= 1000Pt3916
14= 10Cu426
15= 120Ni618
16= 120Ni672
17= 604NiFe518
18= 150ohm
19= 1000ohm
20 = 3000ohm
21= 6000ohm
0
456 InAMod1Ch2Format C.Analog1.Ch02InputFormat_0
C.Analog1.Ch02InputFormat_1
C.Analog1.Ch02InputFormat_2
Assignment for
Analog Module 1
Input Channel 02
Data Format
USINT 1 1 0= EngUnits
1= EngUnitsTimes10
2= RawProportional
3= ScaledForPID
0
457 InAMod1C2TmpUnit C.Analog1.Ch02InputTempMode Assignment for
Analog Module 1
Input Channel 02
Temperature Units
USINT 1 1 0=DegreesC
1=DegreesF
0
458 InAMod1C2FiltFrq C.Analog1.Ch02InputFilter_0
C.Analog1.Ch02InputFilter_1
C.Analog1.Ch02InputFilter_2
Assignment
Analog Module 1
Input Channel 02
Filter Freq
USINT 1 1 0=17Hz
1=4Hz
2=62Hz
3=470Hz
0
459 InAMod1C2OpCktSt C.Analog1.Ch02InputOpenWire_0
C.Analog1.Ch02InputOpenWire_1
Indicates Analog
Module 1 Input
Channel 02 Open
Circuit State
USINT 1 1 0=Upscale
1=Downscale
2=Zero
0
460 InAnMod1Ch2RTDEn C.Analog1.Ch02InputTwoWireRTD Enable Analog
Module 1 Input
Channel 02 to
function with RTD
BOOL 1 1 0=3-wire
1=2-wire
0
461 InAMod1C2TripDly C.Analog1.Ch02InputTripDelay Analog Module 1
Input Channel 02
Trip Delay
USINT 1 10 0 250 10
Second
s
462 InAMod1C2TripLvl C.Analog1.Ch02InputTripLimit Level (in selected
Units) where
Analog Input
generates a trip
UINT 2 1 0 65535 0
463 InAMod1C2WarnLvl C.Analog1.Ch02InputWarnLimit Level (in selected
Units) where
Analog Input
generates a
warning
UINT 2 1 0 65535 0
464 OutAnMod1Type C.Analog1.Ch00OutputRangeType_0
C.Analog1.Ch00OutputRangeType_1
C.Analog1.Ch00OutputRangeType_2
C.Analog1.Ch00OutputRangeType_3
Assignment for
Analog Module 1
Output function
USINT 1 1 0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4=1to5 Volts
5= 0to5 Volts
0
465 OutAnMod1Select C.Analog1.Ch00OutputMode Assignment of
parameter data
value to drive
Analog Module 1
Output
USINT 1 1 0= AveragePctFLA
1= ScaledAvgPctFLA
2= PercentTCU
3= GFCurrent
4= CurrentUnbalance
5= AvgLLVoltage
6=VoltLLUnbalance
7= TotalkW
8= TotalkVA
9= TotalkVAR
10= TotalPF
11= UserDLXData
0
466 OutAnMod1FltActn C.Analog1.Ch00OutputFaultMode_0
C.Analog1.Ch00OutputFaultMode_1
Analog Module 1
Output action on
comms fault
USINT 1 1 0= Zero
1= Maximum
2= Minimum
3= Hold Last State
0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
