Rockwell Automation Allen-Bradley E300

492 Rockwell Automation Publication 193-UM015D-EN-P - November 2013
Appendix B Parameter List
Analog1 Setup
(continued)
467 OutAnMod1IdlActn C.Analog1.Ch00OutputProtectionFaultMode_0
C.Analog1.Ch00OutputProtectionFaultMode_1
Analog Module 1
Output action on
comms idle
USINT 1 1 0= Zero
1= Maximum
2= Minimum
3= Hold Last State
0
Analog2 Setup 468 InAnMod2Ch00Type C.Analog2.Ch00InputRangeType_0
C.Analog2.Ch00InputRangeType_1
C.Analog2.Ch00InputRangeType_2
C.Analog2.Ch00InputRangeType_3
C.Analog2.Ch00InputRangeType_4
Assignment for
Analog Module 2
Input Channel 00
function
USINT 1 1 0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4= 1To5Volts
5= 0To5Volts
6= 100Pt385
7= 200Pt385
8= 500Pt385
9= 1000Pt385
10=100Pt3916
11= 200Pt3916
12= 500Pt3916
13= 1000Pt3916
14= 10Cu426
15= 120Ni618
16= 120Ni672
17= 604NiFe518
18= 150ohm
19= 1000ohm
20 = 3000ohm
21= 6000ohm
0
469 InAMod2Ch0Format C.Analog2.Ch00InputFormat_0
C.Analog2.Ch00InputFormat_1
C.Analog2.Ch00InputFormat_2
Assignment for
Analog Module 2
Input Channel 00
Data Format
USINT 1 1 0= EngUnits
1= EngUnitsTimes10
2= RawProportional
3= ScaledForPID
0
470 InAMod2C0TmpUnit C.Analog2.Ch00InputTempMode Assignment for
Analog Module 2
Input Channel 00
Temperature Units
USINT 1 1 0=DegreesC
1=DegreesF
0
471 InAMod2C0FiltFrq C.Analog2.Ch00InputFilter_0
C.Analog2.Ch00InputFilter_1
C.Analog2.Ch00InputFilter_2
Assignment for
Analog Module 2
Input Channel 00
Filter Freq
USINT 1 1 0=17Hz
1=4Hz
2=62Hz
3=470Hz
0
472 InAMod2C0OpCktSt C.Analog2.Ch00InputOpenWire_0
C.Analog2.Ch00InputOpenWire_1
Indicates Analog
Module 2 Input
Channel 00 Open
Circuit State
USINT 1 1 0=Upscale
1=Downscale
2=Zero
0
473 InAnMod2Ch0RTDEn C.Analog2.Ch00InputTwoWireRTD Enable Analog
Module 2 Input
Channel 00 to
function with RTD
BOOL 1 1 0=3-wire
1=2-wire
0
474 InAMod2C0TripDly C.Analog2.Ch00InputTripDelay Analog Module 2
Input Channel 00
Trip Delay
USINT 1 10 0 250 10
Second
s
475 InAMod2C0TripLvl C.Analog2.Ch00InputTripLimit Level (in selected
Units) where
Analog Input
generates a trip
UINT 2 1 -32768 32767 0
476 InAMod2C0WarnLvl C.Analog2.Ch00InputWarnLimit Level (in selected
Units) where
Analog Input
generates a
warning
UINT 2 1 -32768 32767 0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
